USB-C 3.3V Step-Down Converter front bare PCB render — not assembled PCBA

USB-C 3.3V Step-Down Converter — PCB / PCBA

Price range: $1.00 through $3.20

TPS54331 USB-C buck-converter design for 3.3V embedded power supplies. See the upstream startup-transient note below.

Choose PCB Only — $1.00, 50 g or PCBA — $3.20, 60 g, per piece.

PCBA is made to order: 5-10 days of production after payment confirmation, excluding shipping transit time.

Images show bare PCB renders. The PCB-only option contains no components.

PCB production lead time: 2-3 days. Shipping transit time is additional.

Choose your PCB color: Green, Purple, Red, Yellow, Blue, White, Black or Matte Black.

For bare PCB orders, please enter your preferred soldermask color in the order notes at checkout. If ordering multiple products, specify the product name and color for each item. Example: Arisu PCB – Purple. Product images are references; the supplied PCB color follows your confirmed order requirements.

Prefer to order with your Gerber files? Upload your Gerber files on our PCB/PCBA online ordering page, select your PCB color and manufacturing specifications, and place your order directly. Pricing is calculated from your uploaded files and selected options.

Upload Gerber & Order Online

5% Supports Open Hardware

5% of this product’s net sales goes to the shared DIYIPCB Open Hardware Fund, at no extra charge.

See the fund & rules →
SKU: DIYI-USBC-3V3-BUCK Category: Tags: , , , , ,

Description

USB-C 3.3V Step-Down Converter — PCB / PCBA

Open-source USB-C power-board design by Mauro De Vecchi (maudeve-it), intended to supply a regulated 3.3V rail from a 5V USB-C source.

Main chip

TPS54331: the buck-converter IC identified as U1 in the original KiCad schematic. The project targets up to 3A under suitable source, component and thermal conditions; this is a design target, not a verified continuous-current rating for this listing.

Design functions

  • USB-C input with hardware detection of available source current.
  • 3.3V step-down output and access to the input 5V supply.
  • No USB Power Delivery negotiation controller: this design does not request higher USB-PD voltages.

Typical applications

  • 3.3V power for microcontroller and sensor prototypes.
  • USB-C-powered embedded electronics and development fixtures.
  • Learning buck-converter and USB-C power-interface design.

Actual available power depends on the USB source, cable, load and cooling. The two outputs share the input power budget. These functions require an assembled board; the PCB-only option contains no components.

Choose your build option

Option Price per piece Shipping weight Contents Production lead time
PCB Only USD $1.00 50 g One unpopulated PCB 2-3 days
PCBA USD $3.20 60 g One populated and soldered board 5-10 days after payment confirmation

PCBA is made to order; shipping transit time is additional. Power adapter, cable, enclosure and load are not included. The supplied image is a bare PCB render, not an assembled-product photograph.

Upstream design note

The author reports an approximately 12-second transient after connection to a USB-C PD source and discusses adding a filtering capacitor. Review the original documentation and confirm the manufacturing revision and startup behavior before connecting sensitive equipment. This listing does not claim that the upstream transient has been corrected.

Source and attribution

Copyright (c) 2023 Mauro De Vecchi. Supplied by DIYIPCB; no endorsement by the original designer is implied.

Contact DIYIPCB for revision, assembly and testing requirements.

5% of eligible net sales supports the Open Hardware Fund at no extra charge.

Original MIT license
MIT License

Copyright (c) 2023 Mauro De Vecchi

Permission is hereby granted, free of charge, to any person obtaining a copy
of this software and associated documentation files (the "Software"), to deal
in the Software without restriction, including without limitation the rights
to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
copies of the Software, and to permit persons to whom the Software is
furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all
copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
SOFTWARE.

Additional information

Weight N/A
Build Option

PCB Only, PCBA — 5-10-day production
PCB Production Lead Time

2-3 days
PCBA Production Lead Time

5-10 days
PCB Color (Order Notes)

Green, Purple, Red, Yellow, Blue, White, Black, Matte Black

Maker & product resources

Maker / seller: DIYIPCB · Upstream: Mauro De Vecchi / maudeve-it

Hardware license: MIT

Source repository: https://github.com/maudeve-it/3.3V-3A-step-down-converter-powered-by-USB-C

Documentation: https://github.com/maudeve-it/3.3V-3A-step-down-converter-powered-by-USB-C#readme

Check the product description for specifications, included items, stock and fulfillment details.
