1.54 inE-ink screen module

Low power consumption, wide viewing angle, clear display even when power is off

For display applications such as shelf labels, industrial instruments, etc.
1.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 11.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 2

Selección de versión

1.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 3

Características

  • No backlight is required, and the last screen display content can be kept for a long time when the power is off. The power consumption is very low, and basically only consumes power when refreshing. Provide a complete supporting manual (driver board schematics, Raspberry Pi / Jetson Nano / Arduino and other sample programs) The following is only applicable to the module version SPI control interface, which can be connected to the main control board such as Raspberry Pi / Jetson Nano / Arduino. The onboard level conversion chip is compatible with 3.3V and 5V microcontroller interfaces
  • No backlight required, the last screen display can be kept for a long time after power failure
  • The power consumption is very low, basically only consuming power when refreshing
  • Provide complete supporting manuals (driver board schematics, Raspberry Pi / Jetson Nano / Arduino and other sample programs)The following applies only to the module version

  • SPI control interface, can be connected to Raspberry Pi / Jetson Nano / Arduino and other main control boards

  • Onboard level conversion chip, compatible with 3.3V and 5V microcontroller interfaces

  • Parámetros del producto

  • Tensión de funcionamiento Bare screen version: 3.3V Color de la pantalla Red, yellow, black, white
    Module version: 3.3V / 5V
    Communication interface 3-wire SPI、4-wire SPI Grayscale 2
    Dimensiones Bare screen version: 37.32 × 31.8 × 1.00 (mm) Fast refresh 15s
    Module version: 48.00 × 33.00 (mm) Global Refresh 20s
    Tamaño de la pantalla 27.0 × 27.0 (mm) Refresh power consumption <30mW
    Dot Pitch 0.135 × 0.135 (mm) Sleep current <0.01uA (close to 0)
    Resolución 200 × 200 pixels Ángulo de visión >170°

  • Advantages of E-Ink Screen

    The electronic ink screen uses “microcapsule electrophoretic display” technology to display images. Its working principle is that charged nanoparticles suspended in liquid migrate under the action of the electric field, and form a display effect close to traditional printed paper through reflection under ambient light. The electronic ink screen can display images clearly under ambient light such as light and natural light, without backlight, and the viewing angle is almost 180°. Because its display effect is comparable to that of traditional paper, it is often used in applications such as readers.

    1.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 4

  • SPI control interface

    Can be connected to Raspberry Pi / Jetson Nano / Arduino and other main control boards

    1.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 5

    VCC 3,3 V / 5 V
    GND GND
    ESTRUENDO SPI communication MOSI pin
    CLK SPI Communication SCK Pin
    CS SPI chip select pin (active low)
    corriente continua Data/command control pin (high level indicates data, low level indicates command)
    RST External reset pin (low level reset)
    OCUPADO Busy status output pin

  • Onboard level conversion chip

    Compatible with 3.3V and 5V microcontroller interfaces

    1.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 6

  • Escenario de aplicación

    Applicable to shopping mall price tags, asset equipment labels, electronic shelf labels, conference name tags, etc.

    1.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 7

  • Tamaño del producto

    Naked screen vers1.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 8

    Module version

    1.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 9

1.54inch e-Paper HAT+ (G) E-Ink Red/Yellow/Black/White Display Color 200*200 For Raspberry Pi/Arduino /STM32/Jetson — reference image 10

Personalización de productos

Ofrecemos servicios de personalización de productos. Contáctanos para hablar de sus necesidades.
